Product Description
Bremick® Joist Hangers are typically used in the construction of the roof frame, carports, decks, gazebos, and pergolas. Typical connections include beam to beam, joists and floor trusses to the face of a beam, standard roof truss to a girder truss, jack truss to truncated girder truss, and right-angle joints.
Advantages
The Bremick® Joist Hangers provides numerous benefits including:
- Cost effective. Simple method of connecting two timber members while achieving the required design loads, without the need for costly onsite skilled labour constructing special jointing connections.
- Efficient. Quickly and easily connects the two timber members into a structurally sound application using either Bremick
Timber Connector Nails, Bremick Type 17 12-gauge screws or 32 x 2.5mm screw shank machine fired nails
- Wide Range. Available in a range of widths and depths to suit the most common timber sizes.
- Built-in pre-formed nail in Joist Hanger flange. Allows the installer to easily hold the hanger in position by simply hammering in the pre-formed nails. They can then more easily, quickly and safely nail off the hanger into the supporting
timber member.
Specifications
- Steel Grade: G300
- Thickness: 1.2mm
- Fasteners:
Bremick® 35 x 3.15mm Timber Connector Nails
(Gal or SS316)
32 x 2.5mm Screw Shank Machine Fastened Nails
Bremick® Type 17, 12g x 35mm/65mm Screws
